PUF Insulated Wall Panels

PUF Insulated Wall Panels

Product Details

Density 40+ 2 Kg/m3
Compressive Strength At 10% Deformation 2.1 Kg/cm2
Tensile Strength 4.0 Kg/cm2
Bending Strength 4.2kg/cm2
Adhesion Strength ( Foam to Steel) 3.0 Kg/cm2
Closed Cell Content 90 To95 %
Temprature Range --180 to +140 Degree C
Water Absorbtion 0.1% Volume At 100% Rh

Creative Panel systems are the answer to the Architectural problem of providing high insulation value to the roofing and wall in air conditioning and industrial/commercial building. It provides a one-step solution in the form of a pre-fabricated sandwich polyurethane Panel which ensure exceptional strength since it is a composite system comprising of Profile on one side, linear tray on the inner face and injected CFC free, closed cell high density polyurethane in between. Self-supporting metal panels insulated with PUR for use in industrial and commercial buildings, refrigerated rooms with positive temperature, and partitions in general.


Application of Insulated wall panels :

  • Panel system finds wide applications in the following areas
  • Cold store
  • Post Harvest Management
  • Clean Room
  • CA Rooms
  • Ripening Rooms
  • Telecom Shelter

Self-supporting metal panel, insulated with polyurethane, for pitched roofs with a minimum slope of 7%.


Dimension Stability (48 Hours) :

  • ++ --25degree C - 0.1%
  • ++ +38 degree C at 90% RH - 0.1%
  • ++ +100 degree C - 0.4%
